3S 15A 11.1V 12V 12.6V Lithium Battery Protection Board Charger Protect Module Balance 18650 Li-ion Lipo Cell Pack BMS pcm
Product details of 3S 15A 11.1V 12V 12.6V Lithium Battery Protection Bard Charger Protect Module Balance 18650 Li-ion Lipo Cell
- 3S 15A 11.1V 12V 12.6V Lithium Battery Protection Board Charger Protect Module Balance 18650 Li-ion Lipo Cell25A5.Quiescent current: <30uA6.Internal resistance: <100mΩ7.Equalizing current: 45mA8.Charge voltage: 12.6V-13V9.Overcharge voltage range: 4.25-4.35v±0.05v10.Overdischarge voltage range: 2.3-3.0v±0.05v11.Working temperature: -40---+50℃12.Storage condition: -40-- +80℃13.Effective life: >30000h14.Short-circuit protection: Yes,Delayed self recovery15.Test point description: S1 and S2 short circuit,then P+ and P- will output voltage,it indicates that all MOS protection is normal.16.Note: Do not mix the good battery and poor battery to use.The internal resistance of 3 battery capacity are closer will be better.Please buyers know the professional knowledge of this module before buyingProduct details of 3S 15A 11.1V 12V 12.6V Lithium Battery Protection Bard Charger Protect Module Balance 18650 Li-ion Lipo Cell
- 3S 15A 11.1V 12V 12.6V Lithium Battery Protection Board Charger Protect Module Balance 18650 Li-ion Lipo Cell25A5.Quiescent current: <30uA6.Internal resistance: <100mΩ7.Equalizing current: 45mA8.Charge voltage: 12.6V-13V9.Overcharge voltage range: 4.25-4.35v±0.05v10.Overdischarge voltage range: 2.3-3.0v±0.05v11.Working temperature: -40---+50℃12.Storage condition: -40-- +80℃13.Effective life: >30000h14.Short-circuit protection: Yes,Delayed self recovery15.Test point description: S1 and S2 short circuit,then P+ and P- will output voltage,it indicates that all MOS protection is normal.16.Note: Do not mix the good battery and poor battery to use.The internal resistance of 3 battery capacity are closer will be better.Please buyers know the professional knowledge of this module before buying
